參數
Parameters
|
單位
Unit
|
QB11-3x1300
|
QB11-3x1500
|
QB11-3x1600
|
|
最大剪切板厚
The maximum
shear plate thickness
|
Mm
|
3
|
3
|
3
|
|
最大剪切板寬
The maximum
shear plate plate
|
Mm
|
1300
|
1500
|
1600
|
|
可剪板的強度極限
The ultimate
serength of shearing plate
|
N/mm2
|
≤450
|
≤450
|
≤450
|
|
剪切角度
Shear angle
|
。
|
2°10＇
|
2°
|
2°
|
|
后擋料最大距離
Ater the
expected maximum distance
|
Mm
|
350
|
350
|
350
|
|
行程次數
The number of
strokes
|
Rpm
|
30
|
19
|
19
|
|
主電機功率
Main motor
power
|
Kw
|
4.5
|
4.5
|
4.5
|
|
外形尺寸
Shape size
|
Mm
|
1860x1200x1200
|
2060x1200x1200
|
2200x1360x1260
|
|
機床重量
Weight of
machine
|
Kg
|
1200
|
1300
|
1400
|
